FRONT WHEEL/SUSPENSION/STEERING
15-6
FRONT WHEEL
REMOVAL
Remove the axle nut cap and loosen the front axle
nut.
Disconnect the speedometer cable by releasing the
tab.
Remove the O-ring.
Support the scooter securely using a jack or other
support and raise the front wheel off the ground.
Remove the front axle nut.
Remove the front axle out and remove the front
wheel.
Remove the speedometer gearbox from the right
wheel hub.
O-RING
SPEEDOMETER CABLE
TAB
Do not operate the
brake lever after
removing the front
wheel.
