21. LIGHTS/METERS/SWITCHES
SYSTEM LOCATION································· 21-2
SERVICE INFORMATION ························· 21-3
HEADLIGHT··············································· 21-4
FRONT TURN SIGNAL LIGHT·················· 21-5
REAR COMBINATION LIGHT··················· 21-6
LICENSE LIGHT········································· 21-6
SPEEDOMETER ········································ 21-7
COOLANT TEMPERATURE METER/
ECT SENSOR ············································ 21-9
FUEL METER/FUEL LEVEL
SENSOR·················································· 21-10
IGNITION SWITCH ································· 21-11
HANDLEBAR SWITCHES ······················· 21-12
BRAKE LIGHT SWITCH ·························· 21-13
HORN ······················································ 21-14
TURN SIGNAL RELAY ··························· 21-15
MAIN RELAY ·········································· 21-15
