GENERAL INFORMATION
1-11
STANDARD TORQUE VALUES
ENGINE & FRAME TORQUE VALUES
• Torque specifications listed below are for specified fasteners.
• Others should be tightened to standard torque values listed above.
FRAME/BODY PANELS/EXHAUST SYSTEM
MAINTENANCE
LUBRICATION SYSTEM
FASTENER TYPE
TORQUE
FASTENER TYPE
TORQUE
N·m (kgf·m, lbf·ft) N·m (kgf·m, lbf·ft)
5 mm hex bolt and nut 5.2 (0.53, 3.8) 5 mm screw 4.2 (0.43, 3.1)
6 mm hex bolt and nut
(Include SH flange bolt)
10 (1.0, 7) 6 mm screw 9 (0.92, 6.6)
6 mm flange bolt
(Include NSHF) and nut
12 (1.2, 8.9)
8 mm hex bolt and nut 22 (2.2, 16)
10 mm hex bolt and nut 34 (3.5, 25) 8 mm flange bolt and nut 27 (2.8, 20)
12 mm hex bolt and nut 54 (5.5, 40) 10 mm flange bolt and nut 39 (4.0, 29)
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Front fender mounting bolt 4 6 10 (1.0, 7) Apply locking agent to the
threads.
Floor panel mounting bolt 4 6 7 (0.71, 5.2)
Exhaust pipe joint nut 2 6 14 (1.4, 10)
Muffler mounting bolt 2 10 59 (6.0, 44)
Exhaust pipe stud bolt 2 – – See page 3-13
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Throttle cable lock nut (Throttle
body side)
2 8 8.5 (0.87, 6.3)
Air cleaner element screw 4 5 1.1 (0.11, 0.8)
Air cleaner housing cover screw 7 5 1.1 (0.11, 0.8)
Spark plug 1 10 16 (1.6, 12)
Valve adjusting screw lock nut 2 5 10 (1.0, 7) Apply engine oil to the
threads and seating surface.
Engine oil drain bolt 1 12 24 (2.4, 18)
Engine oil strainer screen cap 1 30 20 (2.0, 15)
Final reduction oil check bolt 1 8 13 (1.3, 10)
Final reduction oil drain bolt 1 8 13 (1.3, 10)
Equalizer connecting cable lock
nut
1 8 6.4 (0.65, 4.7)
Headlight adjusting bolt 1 4 1.8 (0.18, 1.3)
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Oil pump plate screw 1 4 3 (0.31, 2.2)
Oil pump mounting bolt 2 6 10 (1.0, 7)
