GENERAL INFORMATION
1-10
BATTERY/CHARGING SYSTEM SPECIFICATIONS
IGNITION SYSTEM SPECIFICATIONS
ELECTRIC STARTER SPECIFICATIONS
Unit: mm (in)
LIGHTS/METERS/SWITCHES SPECIFICATIONS
ITEM SPECIFICATIONS
Battery Capacity 12 V – 6 Ah
Current leakage 0.1 mA max.
Voltage
(20°C/68°F)
Fully charged Above 12.8 V
Needs
charging
Below 12.3 V
Charging
current
Normal 0.6 A/5 – 10 h
Quick 3.0 A/1.0 h
Alternator Capacity 0.22 kW/5,000 min
-1
(rpm)
Charging coil resistance (20°C/68°F) 0.1 – 1.0 Ω
ITEM SPECIFICATIONS
Spark plug Standard CR7EH-9 (NGK), U22FER9 (DENSO)
For extended high speed riding CR8EH-9 (NGK), U24FER9 (DENSO)
Spark plug gap 0.80 – 0.90 mm (0.031 – 0.035 in)
Ignition coil primary peak voltage 100 V minimum
CKP sensor peak voltage 0.7 V minimum
Ignition timing ("F"mark) 14° BTDC at engine idle speed
ITEM STANDARD SERVICE LIMIT
Starter motor brush length 7.0 (0.28) 3.5 (0.14)
ITEM SPECIFICATIONS
Bulbs Headlight Hi 12 V – 35 W
Lo 12 V – 30 W
Brake/tail light 12 V – 21/5 W
Turn signal light 12 V – 21 W x 4
License light 12 V – 5 W
Instrument light 12 V – 1.7 W x 2
Turn signal indicator 12 V – 3 W x 2
High beam indicator 12 V – 1.7 W
PGM-FI malfunction indicator lamp
(MIL)
LED
Fuse Main fuse 20 A
Sub fuse 10 A x 3
