CYLINDER HEAD/VALVES
9-24
CAM CHAIN GUIDE
REMOVAL
Remove the cylinder head (page 9-7).
Remove the cam chain guide.
INSPECTION
Check the sliding area of the cam chain guide for
excessive wear or damage.
INSTALLATION
Install the cam chain guide by aligning the bosses of
the cam chain guide and grooves of the cylinder.
Install the cylinder head (page 9-21).
