FRAME/BODY PANELS/EXHAUST SYSTEM
3-5
Remove the screw.
Release the four tabs and hook of the side body
cover from the slots by slightly pulling the cover
backward.
Remove the side body cover.
Installation is in the reverse order of removal.
FLOOR PANEL SIDE COVER
REMOVAL/INSTALLATION
Remove the side body cover (page 3-4).
Remove the bolt and screws.
Release the following:
– Tabs of the front side
– Hole of the rear side from the frame
– Three hooks by slightly pulling the cover forward
Remove the floor panel side cover.
Installation is in the reverse order of removal.
SCREW
TABS
SIDE BODY
COVER
HOOK
SCREWS
BOLT
HOOKS
FLOOR PANEL
SIDE COVER
HOLE
TABS
To Next Page
