IGNITION SYSTEM
19-2
IGNITION SYSTEM
SYSTEM LOCATION
SYSTEM DIAGRAM
IGNITION SWITCH
IGNITION COIL
SPARK PLUG
CKP SENSOR
BANK ANGLE SENSOR
ENGINE CONTROL
MODULE (ECM)
ENGINE STOP
RELAY
Y: Yel l o w
R: Red
Bu: Blue
G: Green
Bl: Black
W: White
ENGINE
CONTROL
MODULE
IGNITION
SWITCH
BATTERY CKP SENSOR
R/Bl
R
R
G
G
G
Bl Bl
R/O
BANK
ANGLE
SENSOR
ENGINE STOP
RELAY
IGNITION
COIL
FUSE
20A
FUSE
10A
W/Y
Y
Y/Bu
Bl/W
Bl Bl
Bl/W
Bl/W
O: Orange
