FUEL SYSTEM (Programmed Fuel Injection)
6-54
O2 SENSOR
• Do not get grease, oil or other materials in the O2
sensor air hole.
• The O
2 sensor may be damaged if dropped.
Replace it with a new one, if dropped.
• If the O
2 sensor cap is disconnected, replace the
O
2 sensor cord with a new one, do not reuse O2
sensor cord.
REMOVAL
Replace the O
2
sen-
sor while the
engine is cold.
Remove the following:
– Luggage box (page 3-8)
– Floor panel side cover (page 3-5)
Disconnect the O
2 sensor 2P connector.
Remove the O
2 sensor cap.
Discard the O
2 sensor cord.
Remove the O
2 sensor from the cylinder head.
O2 SENSOR CAP
O2 SENSOR CORD
To Next Page
