FRAME/BODY PANELS/EXHAUST SYSTEM
3-14
CENTERSTAND
REMOVAL/INSTALLATION
Retract the centerstand and support the scooter
securely.
Remove the cotter pin and washer.
Remove the following:
– Springs
– Pivot shaft
– Centerstand
Installation is in the reverse order of removal.
• Apply grease to the pivot areas.
• Always replace the cotter pin with new one.
The centerstand could become noisy when
retracted if the pivot area lacks proper lubrication.
CENTERSTAND
SPRINGS
PIVOT SHAFT
