LIGHTS/METERS/SWITCHES
21-6
REAR COMBINATION LIGHT
BRAKE/TAILLIGHT/REAR TURN SIG-
NAL LIGHT BULB REPLACEMENT
Remove the rear lower body cover (page 3-9).
Turn the bulb socket counterclockwise and remove
it from the rear combination light unit.
Remove the bulb from the socket by pushing in and
turning counterclockwise.
Installation is in the reverse order of removal.
LICENSE LIGHT
BULB REPLACEMENT
Remove the rear lower body cover (page 3-9).
Remove the screws from the license light unit.
Remove the license light unit by unhooking the
hook.
Pull out the license light bulb socket from the light
unit.
Remove the license light bulb from the socket.
Installation is in the reverse order of removal.
BULB
BULB SOCKET
BULB SOCKET
LICENSE LIGHT UNIT
SCREWS
HOOK
BULB SOCKET
LICENSE LIGHT
BULB
BULB
SOCKET
