GENERAL INFORMATION
1-6
LUBRICATION SYSTEM SPECIFICATIONS
Unit: mm (in)
FUEL SYSTEM (PGM-FI) SPECIFICATIONS
COOLING SYSTEM SPECIFICATIONS
ITEM STANDARD SERVICE LIMIT
Engine oil capacity After draining 0.7 liter (0.7 US qt, 0.6 lmp qt) –
After disassembly 0.8 liter (0.8 US qt, 0.7 lmp qt) –
Recommended engine oil API service classification: SG or higher
(except oils labeled as energy conserv-
ing on the circular API service label)
Viscosity: SAE 10W-30
JASO T 903 standard: MB
–
Oil pump rotor Tip clearance 0.15 (0.006) 0.20 (0.008)
Body clearance 0.15 – 0.21 (0.006 – 0.008) 0.35 (0.014)
Side clearance 0.05 – 0.10 (0.002 – 0.004) 0.12 (0.005)
ITEM SPECIFICATIONS
Throttle body identification number GQQ2A
Engine idle speed
1,700 ± 100 min
-1
(rpm)
Throttle grip freeplay 2 – 6 mm (0.08 – 0.24 in)
Fuel injector resistance (at 20°C /68°F) 9 – 12 Ω
PCV solenoid valve resistance (at 20°C /68°F) 30 – 34 Ω
Fuel pressure
294 kPa (3.0 kgf/cm
2
, 43 psi)
Fuel pump flow (at 12 V)
98 cm
3
(3.3 US oz, 3.5 lmp oz) minimum/10 seconds
ITEM SPECIFICATIONS
Coolant capacity Radiator and engine 0.41 liter (0.43 US qt, 0.36 lmp qt)
Reserve tank 0.10 liter (0.11 US qt, 0.09 lmp qt)
Radiator cap relief pressure 108 – 137 kPa (1.1 – 1.4 kgf/cm
2
, 16 – 20 psi)
Thermostat Begin to open 74.5 – 77.5 °C (166 – 172 °F)
Fully open 85 °C (185 °F)
Valve lift 3.5 mm (0.1 in) minimum
Recommended coolant Honda PRE-MIX COOLANT
