LIGHTS/METERS/SWITCHES
21-3
SERVICE INFORMATION
GENERAL
Note the following when replacing the halogen headlight bulb.
– Wear clean gloves while replacing the headlight bulb. Do not put fingerprints on the headlight bulb, as they may create
hot spots on the bulb and cause it to fail.
– If you touch the bulb with your bare hands, clean it with a cloth moistened with alcohol to prevent its early failure.
• A halogen headlight bulb becomes very hot while the headlight is on, and remains hot for a while after it is turned off.
Be sure to let it cool down before servicing.
• Check the battery condition before performing any inspection that requires proper battery voltage.
• Use an electric heating element to heat the water/coolant mixture for the ECT sensor inspection. Keep all flammable
materials away from the electric heating element. Wear protective clothing, insulated gloves and eye protection.
• A continuity test can be made with the switches installed on the scooter.
• Route the wires and cables properly after servicing each component (page 1-17).
• This model utilizes ECT sensor that has two thermistors, for coolant temperature meter and PGM-FI systems.
Refer to the ECT sensor for PGM-FI systems inspection (page 6-52).
• The following color codes are used throughout this section.
SPECIFICATIONS
TORQUE VALUES
Bu: Blue G: Green Lg: Light Green W: White
Bl: Black Gr: Gray O: Orange Y: Yellow
Br: Brown Lb: Light Blue R: Red
ITEM SPECIFICATIONS
Bulbs Headlight Hi 13 V – 35 W
Lo 13 V – 30 W
Brake/tail light 12 V – 21/5 W
Turn signal light 12 V – 21 W x 4
License light 12 V – 5 W
Instrument light 12 V – 1.7 W x 2
Turn signal indicator 12 V – 3 W x 2
High beam indicator 12 V – 1.7 W
PGM-FI malfunction indicator lamp
(MIL)
LED
Fuse Main fuse 20 A
Sub fuse 10 A x 3
Ignition switch protector socket bolt 8.5 N·m (0.87 kgf·m, 6.3 lbf·ft)
