MAINTENANCE
4-6
Throttle grip freeplay can be adjusted at either end
of the throttle cable.
Minor adjustments are made with the upper
adjuster.
Loosen the lock nut and turn the adjuster as
required.
Tighten the lock nut.
• An O-ring is incorporated in the root part of
adjusting nut.
Do not disassemble the throttle cable as it could
damage the O-ring. If damaged, moisture gets
inside the cable, preventing the smooth cable
operation.
Major adjustments are made with the lower
adjuster.
Remove the luggage box (page 3-8).
Loosen the lock nut, turn the adjusting nut as
required and tighten the adjusting nut and lock nut.
Recheck the throttle operation.
Install the removed parts in the reverse order of
removal.
AIR CLEANER
• The viscous paper element type air cleaner can-
not be cleaned because the element contains a
dust adhesive.
• If the scooter is used in unusually wet or dusty
areas, more frequent inspections are required.
Remove the left side body cover (page 3-4).
Remove the seven screws and air cleaner housing
cover.
TORQUE: 8.5 N·m (0.87 kgf·m, 6.3 lbf·ft)
AIR CLEANER
HOUSING COVER
SCREWS
To Next Page
