6. FUEL SYSTEM (Programmed Fuel Injection)
COMPONENT LOCATION ·························· 6-2
SERVICE INFORMATION ··························· 6-3
SYSTEM LOCATION··································· 6-5
SYSTEM DIAGRAM···································· 6-6
ECM TERMINAL ARRANGEMENT ············ 6-7
CONNECTOR LOCATION························· 6-11
PGM-FI TROUBLESHOOTING
INFORMATION ········································· 6-13
SYMPTOM TROUBLESHOOTING ··········· 6-17
MIL CODE INDEX······································ 6-18
ECM POWER/GROUND CIRCUIT
INSPECTION ············································· 6-19
SENSOR UNIT POWER/GROUND
CIRCUIT INSPECTION ······························ 6-21
MIL TROUBLESHOOTING························ 6-22
MIL CIRCUIT INSPECTION······················· 6-31
FUEL LINE INSPECTION ·························· 6-32
FUEL PUMP ·············································· 6-36
FUEL TANK··············································· 6-39
AIR CLEANER HOUSING ························· 6-40
THROTTLE BODY ····································· 6-41
ECM (Engine Control Module)················ 6-48
INJECTOR ················································· 6-48
BANK ANGLE SENSOR ··························· 6-50
ECT SENSOR ············································ 6-52
O
2 SENSOR ··············································· 6-54
IACV (Idle Air Control Valve) ·················· 6-56
INTAKE PIPE ············································· 6-56
PCV SYSTEM············································ 6-58
ENGINE STOP RELAY ······························ 6-61
FUEL PUMP RELAY·································· 6-63
