name gateway-address | gateway-address } [ preference preference ] [ track bfd-session cfg-
name ] [ description description ] command to configure a static route to the site.
You must specify the next hop address on the local device.
----End
11.4.3 (Optional) Configuring RIP Between an MCE and a Site
Context
Do as follows on the MCE.
You need to configure only routing protocols on a device in a site.
Procedure
Step 1 Run the system-view command to enter the system view.
Step 2 Run the rip [ process-id ] vpn-instance vpn-instance-name command to create and enable a
RIP process used by a VPN instance and enter the RIP view.
Step 3 Run the network network-address command to enable RIP routes on the network segment where
the IP address of the VLANIF interface bound to the VPN instance belongs.
Step 4 (Optional) Run the import-route { { static | direct } | { { rip | ospf | isis } [ process-id ] } }
[ cost cost | route-policy route-policy-name ]
*
command to import routes from other routing
protocols.
If another routing protocol is run between an MCE and a PE in this VPN, you need to perform
this step.
----End
11.4.4 (Optional) Configuring OSPF Between an MCE and a Site
Context
Do as follows on the MCE.
You need to configure only routing protocols on a device in a site.
Procedure
Step 1 Run the system-view command to enter the system view.
Step 2 Run the ospf [ process-id | router-id router-id | vpn-instance vpn-instance-name ]
*
command
to create an OSPF process used by a VPN instance and enter the OSPF view.
NOTE
In this step, you must specify vpn-instance vpn-instance-name.
Step 3 (Optional) Run the import-route { limt limt-number | protocol [ process-id ] [ cost cost | route-
policy route-policy-name |tag tag | type type ]
*
} command to import routes from other routing
protocols.
S6700 Series Ethernet Switches
Configuration Guide - IP Routing 11 MCE Configuration
Issue 01 (2012-03-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
634
