KE-2050/KE-2060, KE-2050R/2055R/KE-2060R Maintenance Manual
14-27
14-4-10. Adjusting the Light Ctrl Board Assembly (40001904) and Light Ctrl Board (50)
Assembly (40001918)
[Functions]
These boards control the brightness of each LED lamp.
[Jumper switch settings]
Jumper switches are provided on the Light Ctrl board assembly to be used in the control unit.
Set these jumper switches correctly while referring to the table below.
W1 (14P)
Wholly open
W2 (4P)
Wholly open
W3 (4P)
Open
W4 (2P)
Wholly open
W5 (2P)
Short-circuit
[Adjustment items after replacement]
Adjusting the reference voltage for the LightCtrl board
<Specification>
+8VREF = 8.000 V ± 0.005 V
<Adjusting Method>
c Before attempting to start adjusting the reference voltage, ensure that the DC power
source output voltage has been properly adjusted.
d Using a digital voltmeter, measure the voltage at the check pin TP4(+8VREF). Use TP1
(AGND) for the ground pin.
e Turn the variable resistor VR1 as necessary to make the measurements taken fall within
the specifications.
TP1 TP2 TP3 TP4 CN1
○○○○ OCCLIGHT
VR1 AGND GND
+
24VRE
T
+8VREF
Figure 14-4-10-1 End View of the Light Control Board
Rev. 2.00
