KE-2050/KE-2060, KE-2050R/2055R/KE-2060R Maintenance
Manual
15-5
15-4.
B/U Pin Detection Sensor
15-4-1.
Mounting the B/U
Pin Detection Sensor
②
①
②
①
⑤
⑤
④
③
⑥
⑥
Ｃ
Ｄ
Ａ
Ｂ
Part No.
Part Name
c
40001100
SENSOR BRACKET A (AWC)
d
SL6031092TN SCREW
e
40002237
BU PIN SENS ASM
f
40002239
BU PIN RECEIVE SENS ASM
g
SL6031092TN SCREW
h
HX003140000 SPILAL_TUBE
i
EA9500B0100 CABLE
CLAMP
Rev
. 2.00
273
