Kubota BX24 Workshop Manual

2-S1
BX24, RCK54(P)-23BX, RCK60B-23BX, LA240, BT601, WSM
TRANSAXLE
1. TROUBLESHOOTING
HYDROSTATIC TRANSMISSION
W1022927
Symptom Probable Cause Solution
Reference
Page
System Will Not
Operate in Either
Direction
Oil level is low Check oil level or fill
oil to proper level
G-13
Speed control pedal linkage defective Repair linkage 2-S22
Charge pressure is too low Solution order
1. Replace oil filter
cartridge
G-13
2. Check charge
pressure
2-S12
3. Inspect or flush
charge relief valve
2-S40
Check and high pressure relief valve does not
move smoothly
Inspect or replace
check and high
pressure relief valve
2-S40
Component parts defective Replace hydrostatic
transmission
assembly
2-S23
Vibration and Noise Oil level is too low Check oil level or fill
oil to proper level
G-13
Speed control pedal linkage defective Repair linkage 2-S20
Charge pressure is too low Solution order
1. Replace oil filter
cartridge
G-13
2. Check charge
pressure
2-S12
3. Inspect or flush
charge relief valve
2-S40
Check and high pressure relief valve does not
move smoothly
Inspect or replace
check and high
pressure relief valve
2-S40
Component part is defective Replace hydrostatic
transmission
assembly
2-S23
KiSC issued 08, 2019 A

Kubota BX24 Specifications

General

Engine Power	23 hp (17.2 kW)
Transmission Type	Hydrostatic
Brakes	Wet disc
Power Steering	Yes
Rear PTO	540 RPM
Hydraulic System Type	Open center
3-Point Hitch	Category I
Engine Type	Diesel
Wheelbase	55.1 inches
Width	44.5 inches
Height	85.4 inches
PTO Power	17.7 hp
Gears	2-range (Hi/Lo)
