Kubota BX24 Workshop Manual

3-S3
BX24, RCK54(P)-23BX, RCK60B-23BX, LA240, BT601, WSM
FRONT AXLE
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : See page G-8.)
W1012736
Item N·m kgf·m ft-lbs
Front wheel mounting screw 149.2 to 179.0 15.3 to 18.2 110 to 132
Power steering cylinder hose 23.6 to 27.4 2.4 to 2.8 17.4 to 20.2
Tie-rod slotted nut 17.7 to 34.3 1.8 to 3.5 13.0 to 25.3
Power steering cylinder mounting screw 48.1 to 55.8 4.9 to 5.7 35.5 to 41.2
Bevel gear case mounting screw (M12) 77.5 to 90.2 7.9 to 9.2 57.2 to 66.5
Front gear case cover mounting screw 48.1 to 55.8 4.9 to 5.7 35.5 to 41.2
KiSC issued 08, 2019 A

Kubota BX24 Specifications

General

Engine Power	23 hp (17.2 kW)
Transmission Type	Hydrostatic
Brakes	Wet disc
Power Steering	Yes
Rear PTO	540 RPM
Hydraulic System Type	Open center
3-Point Hitch	Category I
Engine Type	Diesel
Wheelbase	55.1 inches
Width	44.5 inches
Height	85.4 inches
PTO Power	17.7 hp
Gears	2-range (Hi/Lo)
