Kubota BX24 Workshop Manual

3-S1
BX24, RCK54(P)-23BX, RCK60B-23BX, LA240, BT601, WSM
FRONT AXLE
1. TROUBLESHOOTING
W1014322
Symptom Probable Cause Solution
Reference
Page
Front Wheels
Wander to Right or
Left
Tire pressure uneven Adjust G-41
Improper toe-in adjustment (improper alignment) Adjust G-23, 3-S4
Clearance between center pin and pin support
bushing excessive
Replace 3-S14
Front axle rocking force too small Adjust 3-S4
Tie-rod end loose Tighten 3-S8
Air sucked in power steering circuit Bleed –
Front Wheels Can
Not Be Driven
Front wheel driving gears in front axle gear case
broken
Replace 3-S10
Universal joint broken Replace 3-S7
Front wheel drive gears in transmission broken Replace –
Front differential gear broken Replace 3-S11
Noise Gear backlash excessive Adjust or replace 3-S12, S13
Oil insufficient Replenish 3-S5
Bearings damaged or broken Replace –
Gears damaged or broken Replace –
Spiral bevel pinion shaft turning force improper Adjust 3-S13
KiSC issued 08, 2019 A

Kubota BX24 Specifications

General

Engine Power	23 hp (17.2 kW)
Transmission Type	Hydrostatic
Brakes	Wet disc
Power Steering	Yes
Rear PTO	540 RPM
Hydraulic System Type	Open center
3-Point Hitch	Category I
Engine Type	Diesel
Wheelbase	55.1 inches
Width	44.5 inches
Height	85.4 inches
PTO Power	17.7 hp
Gears	2-range (Hi/Lo)
