Kubota BX24 Workshop Manual

4-S3
BX24, RCK54(P)-23BX, RCK60B-23BX, LA240, BT601, WSM
STEERING
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : See page G-8.)
W1012736
Item N·m kgf·m ft-lbs
Steering wheel mounting nut 20 to 25 2.0 to 2.6 14.8 to 18.4
Power steering hose mounting nut 28.4 to 30.0 2.9 to 3.1 20.9 to 22.1
Power steering cylinder hose 23.6 to 27.4 2.4 to 2.8 17.4 to 20.2
Tie-rod slotted nut 17.7 to 34.3 1.8 to 3.5 13.0 to 25.3
Power steering cylinder mounting screw 48.1 to 55.8 4.9 to 5.7 35.5 to 41.2
Tie-rod screw 74 to 84 7.5 to 8.6 54.6 to 61.9
KiSC issued 08, 2019 A

Kubota BX24 Specifications

General

Engine Power	23 hp (17.2 kW)
Transmission Type	Hydrostatic
Brakes	Wet disc
Power Steering	Yes
Rear PTO	540 RPM
Hydraulic System Type	Open center
3-Point Hitch	Category I
Engine Type	Diesel
Wheelbase	55.1 inches
Width	44.5 inches
Height	85.4 inches
PTO Power	17.7 hp
Gears	2-range (Hi/Lo)
