Kubota BX24 Workshop Manual

2-S5
BX24, RCK54(P)-23BX, RCK60B-23BX, LA240, BT601, WSM
TRANSAXLE
2. SERVICING SPECIFICATIONS
W1013874
Item Factory Specification Allowable Limit
Charge Relief Valve
[Oil temperature at 50 C, 122 F]
Setting Pressure 0.55 to 0.75 kPa
5.6 to 7.7 kgf/cm
2
79.8 to 108.8 psi
–
High Pressure Relief Valve
(Forward and Reverse)
[Oil temperature at 50 C, 122 F]
Setting Pressure 19 to 22 MPa
193.8 to 224.4 kgf/cm
2
2775 to 3190 psi
PTO Clutch Operating
Pressure
1.0 to 1.3 MPa
10.2 to 13.3 kgf/cm
2
145.0 to 188.5 psi
PTO Clutch Disc Thickness 1.50 to 1.70 mm
0.060 to 0.066 in.
1.35 mm
0.053 in.
Separate Plate Thickness 0.945 to 1.055 mm
0.0373 to 0.0413 in.
0.80 mm
0.0310 in.
Back Plate Thickness 1.9 to 2.1 mm
0.075 to 0.082 in.
1.85 mm
0.073 in.
Clutch Piston Flatness – 0.15 mm
0.0059 in.
Pressure Plate and Steel Plate Flatness – 0.20 mm
0.0079 in.
Clutch Spring Free Length 38.5 mm
1.52 in.
34.5 mm
1.36 in.
PTO Brake Disc Thickness 2.9 to 3.1 mm
0.115 to 0.122 in.
2.70 mm
0.106 in.
PTO Brake Plate Thickness 1.9 to 2.1 mm
0.075 to 0.082 in.
1.85 mm
0.073 in.
Differential Case to Differential Side Gear
Differential Case
Differential Side Gear
Clearance
I.D.
O.D.
0.050 to 0.151 mm
0.0020 to 0.0059 in.
38.000 to 38.062 mm
1.4961 to 1.4985 in.
37.911 to 37.950 mm
1.4926 to 1.4941 in.
0.30 mm
0.0118 in.
–
–
Differential Pinion Shaft to Differential
Pinion
Differential Pinion
Differential Pinion Shaft
Clearance
Differential Pinion
(I.D.)
Differential Pinion
Shaft
(O.D.)
0.080 to 0.122 mm
0.0031 to 0.0048 in.
20.060 to 20.081 mm
0.7898 to 0.7906 in.
19.959 to 19.980 mm
0.7858 to 0.7866 in.
0.30 mm
0.0118 in.
–
–
KiSC issued 08, 2019 A

Kubota BX24 Specifications

General

Engine Power	23 hp (17.2 kW)
Transmission Type	Hydrostatic
Brakes	Wet disc
Power Steering	Yes
Rear PTO	540 RPM
Hydraulic System Type	Open center
3-Point Hitch	Category I
Engine Type	Diesel
Wheelbase	55.1 inches
Width	44.5 inches
Height	85.4 inches
PTO Power	17.7 hp
Gears	2-range (Hi/Lo)
