Kubota BX24 Workshop Manual

2-S7
BX24, RCK54(P)-23BX, RCK60B-23BX, LA240, BT601, WSM
TRANSAXLE
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : See page G-8.)
W1012736
Item N·m kgf·m ft-lbs
Charge relief valve checking plug (R 1/4) 29 to 44 3.0 to 4.5 21.4 to 32.5
Hexagon socket head plug (R 1/4) 29 to 44 3.0 to 4.5 21.4 to 32.5
Check and high pressure valve screw 2.5 to 3.0 0.26 to 0.31 1.8 to 2.2
PTO clutch operating pressure plug (R 1/8) 13 to 22 1.3 to 2.2 9.6 to 16.2
ROPS mounting nut 124 to 147 12.6 to 15.0 91.2 to 108
Fuel tank stay mounting bolt 48.1 to 55.9 4.9 to 5.7 35.4 to 41.2
Fender bracket mounting bolt 124 to 147 12.6 to 15.0 91.2 to 108
Rear wheel mounting bolt 108.5 to 130.2 11.1 to 13.3 80 to 96
Sub frame mounting bolt and nut (M14) 147 15.0 108.5
Sub frame mounting bolt and nut (M16) 196 20.0 147
Hitch plate mounting bolt and nut (M14) 124 to 147 12.6 to 15.0 91.2 to 108
Fender bracket mounting bolt and nut (M14) 124 to 147 12.6 to 15.0 91.2 to 108
Transaxle assembly mounting bolt (M12) 62.8 to 72.6 6.4 to 7.4 46.3 to 53.5
Transaxle assembly mounting bolt (M14) 124 to 147 12.6 to 15.0 91.2 to 108
Rear coupling mounting bolt 23.6 to 27.4 2.4 to 2.8 17.4 to 20.2
Front coupling mounting bolt (M8) 23.6 to 27.4 2.4 to 2.8 17.4 to 20.2
HST fan mounting bolt (M8) 9.8 to 11.3 1.0 to 1.2 7.2 to 8.3
Hydraulic control lever mounting bolt and nut 17.7 to 20.6 1.8 to 2.1 13.0 to 15.2
HST front cover mounting bolt and nut 18.0 to 21.0 1.8 to 2.1 13.3 to 15.5
Check and high pressure relief valve plug (G 1/2) 59.0 to 78.0 6.0 to 8.0 43.5 to 57.5
Hydraulic cylinder mounting bolt 39.2 to 44.1 4.0 to 4.5 28.9 to 32.5
Transaxle case front cover mounting bolt (M8) 29 to 34 3.0 to 3.5 21.4 to 25.1
Hydraulic pump assembly mounting bolt (M6) 8.0 to 9.0 0.8 to 0.9 5.9 to 6.6
Hydraulic pump assembly mounting bolt (M8) 18.0 to 21.0 1.8 to 2.1 13.3 to 15.5
Rear PTO cover mounting bolt (M8) 18.0 to 21.0 1.8 to 2.1 13.3 to 15.5
Rear axle case (RH) mounting bolt (M8) 18.0 to 21.0 1.8 to 2.1 13.3 to 15.5
66T final gear mounting bolt 60.8 to 70.6 6.2 to 7.2 44.8 to 52.1
KiSC issued 08, 2019 A

Kubota BX24 Specifications

General

Engine Power	23 hp (17.2 kW)
Transmission Type	Hydrostatic
Brakes	Wet disc
Power Steering	Yes
Rear PTO	540 RPM
Hydraulic System Type	Open center
3-Point Hitch	Category I
Engine Type	Diesel
Wheelbase	55.1 inches
Width	44.5 inches
Height	85.4 inches
PTO Power	17.7 hp
Gears	2-range (Hi/Lo)
