1-S10
BX24, RCK54(P)-23BX, RCK60B-23BX, LA240, BT601, WSM
ENGINE
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(Tractor section for general use screws, bolts and nuts : See page G-8.)
Tractor Section
W1012736
Engine Section
NOTE
In removing and applying the bolts and nuts marked with “*”, a pneumatic wrench or similar pneumatic
tool, if employed, must be used with enough care not to get them seized.
For * marked screws, bolts and nuts on the table, apply engine oil to their threads and seats before
tightening.
The letter “M” in Size Pitch means that the screw, bolt or nut dimension stands for metric. The size is
the nominal outside diameter in mm of the threads. The pitch is the nominal distance in mm between two
threads.
W1013236
Item N·m kgf·m ft-lbs
Front coupling mounting bolt
Engine mounting nut
Cushion mounting nut
23.6 to 27.4
23.6 to 27.4
23.6 to 27.4
2.4 to 2.8
2.4 to 2.8
2.4 to 2.8
17.4 to 20.2
17.4 to 20.2
17.4 to 20.2
Item Size x Pitch N·m kgf·m ft-lbs
*Cylinder head screw M8 x 1.25 37.3 to 42.2 3.8 to 4.3 27.5 to 31.1
Oil pressure switch PT 1/8 14.7 to 19.6 1.5 to 2.0 10.8 to 14.5
Engine oil filter joint 39.2 to 49.0 4.0 to 5.0 29.0 to 36.3
Nozzle holder 34.3 to 39.2 3.5 to 4.0 25.3 to 28.9
Overflow pipe retaining nut M12 x 1.5 19.6 to 24.5 2.0 to 2.5 14.5 to 18.1
Nozzle holder assembly M20 x 1.5 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
*Cylinder head cover screw M6 x 1 6.86 to 11.3 0.7 to 1.15 5.1 to 8.3
Injection pipe retaining nut M12 x 1.5 24.5 to 34.3 2.5 to 3.5 18.1 to 25.3
Glow plug M8 x 1 7.8 to 14.7 0.8 to 1.5 5.8 to 10.8
*Rocker arm bracket nut M6 x 1 9.8 to 11.3 1.00 to 1.15 7.2 to 8.3
*Fan drive pulley screw M12 x 1.5 117.7 to 127.5 12.0 to 13.0 86.8 to 94.0
*Idle gear shaft mounting screw M6 x 1 9.8 to 11.3 1.00 to 1.15 7.2 to 8.3
*Connecting rod screw M7 x 0.75 26.5 to 30.4 2.7 to 3.1 19.5 to 22.4
*Flywheel screw M10 x 1.25 53.9 to 58.8 5.5 to 6.0 39.8 to 43.4
Bearing case cover mounting screw M6 x 1 9.8 to 11.3 1.00 to 1.15 7.2 to 8.3
*Main bearing case screw 2 M7 x 1 26.5 to 30.4 2.7 to 3.1 19.5 to 22.4
*Main bearing case screw 1 M6 x 1 12.7 to 15.7 1.3 to 1.6 9.4 to 11.6
