G-12
BX24, RCK54(P)-23BX, RCK60B-23BX, LA240, BT601, WSM
G GENERAL
[2] CHECK POINTS OF INITIAL 50 HOURS
Changing Engine Oil
• Be sure to stop the engine before changing engine oil.
1. Start and warm up the engine for approx. 5 minutes.
2. Place an oil pan underneath the engine.
3. To drain the used oil, remove the drain plug (1) at the bottom of
the engine and drain the oil completely.
4. Screw in the drain plug (1).
5. Fill new oil up to upper line on the dipstick (3).
• When using an oil of different manufacture or viscosity from
the previous one, remove all of the oid oil.
• Never mix two different types of oil.
• Use the proper SAE Engine Oil according to ambient
temperatures.
• Refer to “LUBRICANTS, FUEL AND COOLANT”. (See page
G-7.)
W1014065
Replacing Engine Oil Filter
• Be sure to stop the engine before changing oil filter
cartridge.
1. Remove the oil filter.
2. Put a film of clean engine oil on the rubber seal of the new filter.
3. Tighten the filter quickly until it contacts the mounting surface.
Tighten filter by hand an additional 1/2 turn only.
4. After the new filter has been replaced, the engine oil normally
decrease a little. Make sure that the engine oil does not leak
through the seal and be sure to check the oil level on the dipstick.
Then, replenish the engine oil up to the specified level.
5. Properly dispose of used oil.
• To prevent serious damage to the engine, replacement
element must be highly efficient. Use only a KUBOTA
genuine filter or its equivalent.
W1014316
Engine oil capacity
3.1 L
3.3 U.S.qts
2.7 Imp.qts
(1) Drain Plug
(2) Oil Inlet
(3) Dipstick
(A) Oil level is acceptable within this
range.
(1) Engine Oil Filter Cartridge
To Next Page
