G-45
BX24, RCK54(P)-23BX, RCK60B-23BX, LA240, BT601, WSM
G GENERAL
10. IMPLEMENT LIMITATIONS
The KUBOTA Tractor has been thoroughly tested for proper performance with implements sold or approved by
KUBOTA. Use with implements which exceed the maximum specifications listed below, or which are otherwise unfit
for use with the KUBOTA Tractor may result in malfunctions or failures of the tractor, damage to other property and
injury to the operator or others. [Any malfunctions or failures of the tractor resulting from use with improper implements
are not covered by the warranty.]
• Implement size may vary depending on soil operating conditions.
Tread (max. width) with farm tires
Lower link end max. loading
weight W
0
Front Rear
BX24 910 mm (35.8 in.) 820 mm (32.2 in.) 550 kg (1210 lbs)
Actual figures
Implement weight W
1 and /
or size
Max. Drawbar Load W
2
Trailer loading weight W3
Max. capacity
BX24
As in the following list
(Shown on the next page)
250 kg (550 lbs) 800 kg (1765 lbs)
Lower link end max. hydraulic lifting capacity .....W
0
Implement weight..............................................The implement’s weight which can be put on the lower link : W1
Max. drawbar load .............................................W2
Trailer loading weight .........................................The max. loading weight for trailer (without trailer’s weight ) : W3
