Lantronix SLC 8000 User Manual

8: Device Ports
SLC™ 8000 Advanced Console Manager User Guide 155
Host Lists
A host list is a prioritized list of SSH, Telnet, and TCP hosts available for establishing incoming
modem connections or for the connect direct command on the CLI. The SLC unit cycles
through the list until it successfully connects to one.
To add a host list:
1. Click the Devices tab and select the Host Lists option. The following page displays:
Figure 8-13 Devices > Host Lists
2. Enter the following:
Note: To clear fields in the lower part of the page, click the Clear Host List button.
3. You have the following options:
- To save the host list without adding hosts at this time, click the Add Host List button.
- To add hosts, enter the following:
Host List Id Displays after a host list is saved.
Host List Name Enter a name for the host list.
Retry Count Enter the number of times the SLC advanced console manager should attempt
to retry connecting to the host list.
Authentication Select to require authentication when the SLC unit connects to a host.

Lantronix SLC 8000 Specifications

General

Rack mounting	Yes
Console port	RJ-45
Serial ports quantity	48
USB 2.0 ports quantity	2
AC input voltage	120-230 V
Power source type	AC
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	5030 g
Dimensions (WxDxH)	436.9 x 304.8 x 43.18 mm
