SLC™ 8000 Advanced Console Manager User Guide 32
3: Installation
This chapter provides a high-level procedure for installing the SLC advanced console manager
followed by more detailed information about the SLC connections and power supplies.
Caution: To avoid physical and electrical hazards, please read
Appendix A: Security Considerations on page 387 before installing the
SLC 8000 advanced console manager.
What's in the Box
Table 3-1 lists all included components that come in the box and their corresponding part
numbers.
Table 3-1 What’s in the Box
Part Number Component Description
SLC 8000 Advanced Console Manager Models
SLC80162211S SLC 8000 Advanced Console Manager with RJ45 16-Port, Dual SFP, Dual AC PSU
SLC80162411S SLC 8000 Advanced Console Manager with RJ45 16-Port, Dual SFP, Dual DC PSU
SLC80322211S SLC 8000 Advanced Console Manager with RJ45 32-Port, Dual SFP, Dual AC PSU
SLC80482211S SLC 8000 Advanced Console Manager with RJ45 48-Port, Dual SFP, Dual AC PSU
SLC81162211S SLC 8000 Advanced Console Manager with USB 16-Port, Dual SFP, Dual AC PSU
SLC81162411S SLC 8000 Advanced Console Manager with USB 16-Port, Dual SFP, Dual DC PSU
SLC80081201S* SLC 8000 Advanced Console Manager with RJ45 8-Port, Dual Ethernet, Single AC PSU
SLC80082201S* SLC 8000 Advanced Console Manager with RJ45 8-Port, Dual Ethernet, Dual AC PSU
SLC81161201S* SLC 8000 Advanced Console Manager with USB 6-Port, Dual Ethernet, Single AC PSU
SLC80161201S* SLC 8000 Advanced Console Manager with RJ45 16-Port, Dual Ethernet, Single AC PSU
SLC80162201S SLC 8000 Advanced Console Manager with RJ45 16-Port, Dual Ethernet, Dual AC PSU
SLC80162401S SLC 8000 Advanced Console Manager with RJ45 16-Port, Dual Ethernet, Dual DC PSU
SLC80321201S* SLC 8000 Advanced Console Manager with RJ45 32-Port, Dual Ethernet, Single AC PSU
SLC80322201S* SLC 8000 Advanced Console Manager with RJ45 32-Port, Dual Ethernet, Dual AC PSU
SLC80322401S SLC 8000 Advanced Console Manager with RJ45 32-Port, Dual Ethernet, Dual DC PSU
SLC80481201S* SLC 8000 Advanced Console Manager with RJ45 48-Port, Dual Ethernet, Single AC PSU
SLC80482201S* SLC 8000 Advanced Console Manager Serial RJ45 48-Port, Dual Ethernet, Dual AC
PSU
SLC80482401S SLC 8000 Advanced Console Manager Serial RJ45 48-Port, Dual Ethernet, Dual DC
PSU
Cables
200.2070A RJ45 to DB9F Adapter
Note: Available only with SLC 8000 units with RJ-45 modules.
200.0062 RJ45 to RJ45, Cat5, 6.6 ft (2 m)
Note: Available only with SLC 8000 units with GbE variants.

Lantronix SLC 8000 Specifications

General

Rack mounting	Yes
Console port	RJ-45
Serial ports quantity	48
USB 2.0 ports quantity	2
AC input voltage	120-230 V
Power source type	AC
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	5030 g
Dimensions (WxDxH)	436.9 x 304.8 x 43.18 mm
