Lantronix SLC 8000 User Manual

8: Device Ports
SLC™ 8000 Advanced Console Manager User Guide 157
Figure 8-14 View Host Lists
2. View, add, or update the following:
Host Parameters
Host List Id Displays after a host list is saved.
Host List Name Enter a name for the host list.
Retry Count Enter the number of times the SLC 8000 advanced console manager should
attempt to retry connecting to the host list.
Authentication Select to require authentication when the SLC unit connects to a host.
Host Name or IP address of the host.
Protocol Protocol for connecting to the host (TCP, SSH, or Telnet).
Port Port on the host to connect to SLC advanced console manager
Escape Sequence The escape character used to get the attention of the SSH or Telnet client. It is
optional, and if not specified, Telnet and SSH use their default escape character.
For Telnet, the escape character is either a single character or a two-character
sequence consisting of '^' followed by one character. If the second character is '?',
the DEL character is selected. Otherwise, the second character is converted to a
control character and used as the escape character.
For SSH, the escape character is a single character.

Lantronix SLC 8000 Specifications

General

Rack mounting	Yes
Console port	RJ-45
Serial ports quantity	48
USB 2.0 ports quantity	2
AC input voltage	120-230 V
Power source type	AC
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	5030 g
Dimensions (WxDxH)	436.9 x 304.8 x 43.18 mm
