Lantronix SLC 8000 User Manual

SLC™ 8000 Advanced Console Manager User Guide 193
10: Remote Power Managers
The SLC supports managing remote power managers (RPMs) for devices from over 140 vendors.
The RPMs can be either PDUs or UPSes, and can be managed via SNMP, serial port, network
and USB connections. The RPMs web page displays a list of all currently managed RPMs with an
overview of their current status, with options to control and view detailed status for each RPM,
depending on its supported capabilities.
Network and SNMP managed RPMs are disabled in FIPS mode. The only action that can be
performed on a network or SNMP managed RPM in FIPS mode is that it can be deleted via the
CLI.
For notes on optimizing the management of specific devices, see
Optimizing and Troubleshooting RPM Behavior (on page 205).
Devices - RPMs
To control or view status for an RPM:
1. Click the Devices tab and select the RPMs option. The RPMs page displays.
Figure 10-1 Devices > RPMs
2. In the lower section of the page, select an RPM by clicking on the radio button to the far right
in the RPM's row. The options that are available for that RPM will be available (ungreyed).
Select one of the following options:
Refresh Refreshes the information in the RPMs table.
Add Device Displays the Device Ports > RPMs - Add Device to add a new
managed PDU or UPS.
Shutdown Order Displays the order in which all UPS devices are shutdown in the event
that a UPS reaches a low battery state. See Figure 10-2. For more
information, see RPM Shutdown Procedure.

Lantronix SLC 8000 Specifications

General

Rack mounting	Yes
Console port	RJ-45
Serial ports quantity	48
USB 2.0 ports quantity	2
AC input voltage	120-230 V
Power source type	AC
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	5030 g
Dimensions (WxDxH)	436.9 x 304.8 x 43.18 mm
