Lantronix SLC 8000 User Manual

13: Maintenance
SLC™ 8000 Advanced Console Manager User Guide 286
Diagnostics
The Maintenance > Diagnostics page provides methods for diagnosing problems such as network
connectivity and device port input/output problems. You can use equivalent commands on the
command line interface.
1. Click the Maintenance tab and select the Diagnostics option. The following page displays:
Figure 13-7 Maintenance > Diagnostics
2. Select Diagnostics from checklist (one or more diagnostic methods you want to run, or select
All to run them all):
IPv4 ARP Table The IPv4 Address Resolution Protocol (ARP) table used to view the IP address-to-
hardware address mapping.
IPv6 Neighbor
Table
The IPv6 Neighbor table is used to view a list of neighbor's IPv6 addresses on the same
network, and their corresponding MAC addresses.
Netstat Displays network connections. If you select the checkbox, select the TCP or UDP protocol,
or select All for both protocols to control the output of the Netstat report.

Lantronix SLC 8000 Specifications

General

Rack mounting	Yes
Console port	RJ-45
Serial ports quantity	48
USB 2.0 ports quantity	2
AC input voltage	120-230 V
Power source type	AC
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	5030 g
Dimensions (WxDxH)	436.9 x 304.8 x 43.18 mm
