Lantronix SLC 8000 User Manual

12: User Authentication
SLC™ 8000 Advanced Console Manager User Guide 223
Figure 12-4 User Authentication > Local/Remote User > Add/Edit User
2. Enter the following information for the user:
Login User ID of selected user.
Authentication Select the type of authenticated user:
 Local: User listed in the SLC database.
 Remote: User not listed in the SLC database.
UID A unique numeric identifier the system administrator assigns to each user.
Valid UIDs are 101-4294967295.
Note: The UID must be unique. If it is not, SLC unit automatically increments
it. Starting at 101, the SLC 8000 advanced console manager finds the next
unused UID.
Listen Ports The device ports that the user may access to view data using the connect
listen command. Enter the port numbers or the range of port numbers (for
example, 1, 5, 8, 10-15). U1 and U2 denote the USB upper and lower ports on
the front of the SLC unit.
Data Ports The device ports with which the user may interact using the connect direct
command. Enter the port numbers or the range of port numbers.
Clear Port Buffers
The device port buffers the users may clear using the set locallog
clear
command. Enter the port numbers or the range of port numbers.

Lantronix SLC 8000 Specifications

General

Rack mounting	Yes
Console port	RJ-45
Serial ports quantity	48
USB 2.0 ports quantity	2
AC input voltage	120-230 V
Power source type	AC
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	5030 g
Dimensions (WxDxH)	436.9 x 304.8 x 43.18 mm
