5-68 Image Optimization
To ensure the correctness of the results, please select an image with clear follicle boundary
when entering smart FLC.
5.10.13.2 Operation Controls
Edit ROI
Same as the operation in ROI editing in Smart-V.
Edit/ Undo
Tap [Edit] on touch screen to turn on the editing function. It supports dividing, merging, adding and
deleting of the follicle.
Tap [Undo], [Redo] or [Undo All] on touch screen to undo, redo or cancel previous editing.
Zoom
Same as those in 3D/4D mode.
Annotation and Body Mark
Same as those in other modes.
Measurement
2D related measurement can be performed on MPR. For details, please refer to [Advanced Volume].
Save the image
The Smart FLC supports saving single-frame image only, does not support saving multi-frame cine file.
5.10.14 Smart Planes CNS
The doctor finds fetus’s sagittal view by judgments on image features, and then makes an observation.
The fetus’s s sagittal view is hard to be detected or cannot be detected sometimes because of the
fetus's move inside.
Taking the key anatomical tissues and organs's features from 3D data of fetus’s intracranial, Smart
Planes CNS is a mode-wise technology, which detects the middle of the fetus’s sagittal view, transverse
plane of thalami, transverse plane of lateral ventricles and transverse plane of cerebellum. It helps the
