Mindray DC-80A User Manual

5-96 Image Optimization
Description of select mode controls:
Touch screen controls:
Selection
Description
Stages: XX Rotate the corresponding knob under the button to select a stage.
Views: XX Rotate the corresponding knob under the button to select a view.
Acquire/
Select/
Review/WMS
To switch the mode status.
1. Clip
/2. Clip
/3. Clip
/4. Clip
For selecting views in the selected stage.
Next
Next four Clips.
Previous
Previous four Clips.
First
Go to “first” Clips.
Last
Go to “last” Clips.
Play Click to play/stop cine play.
Prev frame
See previous frame of the cine file.
Next frame
See next frame of the cine file.
First frame
See first frame of the cine file.
Last frame
See last frame of the cine file.
/
Decreases or increases playback speed.
Phase/view
selection
Cine
controls
Other
controls
Mode
