Mindray DC-80A User Manual

B-2 Barcode Reader
2. Scan window Scan the barcode.
3.
Trigger
Press to decode
B.1.2 Setting Up the Reader (Take LS2208 as an
example)
1. Plug the interface cable modular connector into the cable interface port on the
bottom of the reader handle, and ensure the connector is properly secured.
2. Connect the other end of the interface cable to the host.
1. Cable interface port
2. Interface cable modular connector
B.1.3 Setting
The reader has factory settings; please refer to A.4 for details.
The reader supports some user-defined functions as introduced below.
For more details, please contact the SYMBOL reader agents or Mindray Customer
Service Department.
 Volume setting:
Scan the following barcode to set the volume parameter.
