B-12 Barcode Reader
B.3 Setting in Ultrasound System
Press <Setup> to enter the Setup menu and select [Scan Code] to see the following
screen.
1-dimension barcode reader (1D):
Scan Item
After scanning 1D bar code, the regular expression is matched in the
priority order: “Patient ID -> Other ID -> First name -> Last name ->
Middle name -> Accession# -> Operator -> Diagnostician”. If the regular
expression is matched successfully, the data of 1D bar code will be
displayed in this item in Patient page automatically.
Example: The data of the bar code is 123 after scanning 1D bar code.
The regular expression is matched in the priority order: “Patient ID ->
Other ID -> First name -> Last name -> Middle name -> Accession# ->
Operator -> Diagnostician”. If the regular expression of "Other ID" is
matched successfully, “123” will be displayed in “Other ID” item in Patient
page automatically.
Regular
Expression
Set the regular expression according to the bar code format.
To Next Page
