Total hours with heaters on: 14
Melter
Configuration code:
Field bus data protocol: Standard
ACM 1:
ACM 2:
Control system
Software vers.:
Recipe vers.:
Temperature controller
No. 1:
No. 2:
No. 3:
I/O board
No. 1:
No. 2:
Profibus board:
Control system
Pressure sensor
A1:
A2:
A3:
B1:
B3:
B4:
C1:
C2:
C3:
C4:
Control system
Temperature controller
Nr.4:
Nr.5:
Nr.6:
I/O board
ACM 1:
ACM 2:
Nr.7:
Nr.8:
Nr.9:
Operation
4-39
P/N 7105144G
 2008 Nordson Corporation
VersaBlue_NW
Information (Melter and Control System)
Total hours with heaters on: This value indicates the hours that the
heaters were switched on.
Fig. 4-33 V5
The software configuration code, the type of field bus data protocol, the
firmware and software versions as well as the pressure sensor used are
shown in the subsequent screens.
NOTE: The displayed code and the code on the ID plate should be the
same. If the configuration code changes, e.g. after retrofitting, both of the
old ID plates should be replaced to avoid any misunderstandings.
Fig. 4-34 V5.1
Software vers. Version of control panel software
X.YY.ZZZ (example: 1.00.000)
Fig. 4-35 V6
Pressure Sensors Used
Fig. 4-36 V6.2
ACM Information
Fig. 4-37 V6.1
