Maintenance
5-5
P/N 7105144G
2008 Nordson Corporation
VersaBlue_NW
Visual Inspection for External Damage
WARNING: When damaged parts pose a risk to the operational safety of
the melter and/or safety of personnel, switch off the melter and have the
damaged parts replaced by qualified personnel. Use only original Nordson
spare parts.
Safety and Function Tests
During power up of the melter, the lights in the light tower are all switched
on briefly as a test. The operator should check whether all lights function
properly. Replace defective lamps.
Detaching Protective Panels
Open the protective panels with a 4 mm Allan key.
On the inside
Fig. 5-1
Detaching Insulation Blanket
1. Release Velcro and clamps.
2. Take insulation blanket out of hooks.
2
1
2
1
Fig. 5-2
