Left
Right
Repair
7-27
P/N 7105144G
2008 Nordson Corporation
VersaBlue_NW
Calibrating
CAUTION: When calibrating, keep hands or conducting tools away from
coaxial connections (11 to 15) to prevent distortion of the signal.
Prerequisites
Level sensor is installed, fastened mechanically and connected
electrically.
Observe the sensor cable color. The English abbreviation of the color is
engraved on the board.
Tank empty
Level sensor is clean
Operating voltage is applied (LED Operating voltage (6) lit).
1. Turn potentiometer P3 (10, Fig. 7-41) until the LED Tank empty
(1, Fig. 7-41) just begins to light up.
2. Turn back to the switching point when the LED Tank empty just goes off.
3. From the switching point, turn half of a revolution more to the left.
NOTE: The closer the setting is to the switching point, the higher the
sensitivity.
4. Turn potentiometer P4 (9, Fig. 7-41) until all of the LEDs (2 to 5,
Fig. 7-41) just begin to light up. Manufacturing tolerances may cause the
LEDs to light up at different times.
5. Turn back to the switching point when LEDs 2 to 5 just go off.
Fig. 7-42 Direction
6. From the switching point, turn half of a revolution more to the left.
