Min.:
789
456
123
.0
100.0Max.:
1.0
NAME
1234567890
QWE R T Y U I OP
ASDFGHJKL
ZXCVBNM_
1. Switch off main contactor
and wait 3 min!
Replacing motor controller
New MC
Main
contactor
Operation
4-3
P/N 7105144G
2008 Nordson Corporation
VersaBlue_NW
Input Window
When a field for entering a numerical value is touched, this input window
with the limits Min. and Max. appears.
Fig. 4-1
When a field for entering a name is touched, this input window appears.
Fig. 4-2
Screen Motor Controller Replacement
This screen appears automatically when more than one motor controller has
been replaced. It is not protected by password.
For information on how to proceed, refer to the section Repair, On the
Control Panel: Allocating Replaced Motor Controllers (MC) to their Motors.
Fig. 4-3
