Nordson VersaBlue VB Series User Manual

2
1
Introduction
2-9
P/N 7105144G
 2008 Nordson Corporation
VersaBlue_NW
Identification of Hose Connections
The melter supplies various adhesive streams (pump streams) that are
guided through the hoses to the different gear metering pump stations or
guns. Engraved numbers identify the hose connections so that the pump
streams can be correctly paired with the hoses.
The hose connection that leads down is number 1, the one above it number
2. The hose connections are numbered from right to left beginning with 1.
NOTE: Two hose connections per single-stream pump are possible. Four
hose connections per double-stream pump are possible.
Fig. 2-8
Example 1: Hose connection numbering for single-stream pumps
Pump number
4 3 2 1
Numbers
Top: 2 Top: 2 Top: 2 Top: 2
Bottom: 1 Bottom: 1 Bottom: 1 Bottom: 1
Possible hose connections 4.1
4.2
3.1
3.2
2.1
2.2
1.1
1.2
Example 2: Hose connection numbering for double-stream pumps
Pump number
4 3 2 1
Pump stream
(filter cartridge)
Right: 4.1
Left: 4.2
Right: 3.1
Left: 3.2
Right: 2.1
Left: 2.2
Right: 1.1
Left: 1.2
Numbers
Top: 2 Top: 2 Top: 2 Top: 2
Bottom: 1 Bottom: 1 Bottom: 1 Bottom: 1
Possible hose connections 4.1.1
4.1.2
4.2.1
4.2.2
3.1.1
3.1.2
3.2.1
3.2.2
2.1.1
2.1.2
2.2.1
2.2.2
1.1.1
1.1.2
1.2.1
1.2.2
