Separate Line Speed Signal Inputs
Fig. 3-19
XS5.1 (3-pin)
Pin Input Function
1 − (Ground) Analog input
2 0 to 10 V
DC
Pin 3 not assigned
XS5.2 (3-pin)
Pin Input Function
1 − (Ground) Analog input
2 0 to 10 V
DC
Pin 3 not assigned
XS5.3 (3-pin)
Pin Input Function
1 − (Ground) Analog input
2 0 to 10 V
DC
Pin 3 not assigned
XS5.4 (3-pin)
Pin Input Function
1 − (Ground) Analog input
2 0 to 10 V
DC
Pin 3 not assigned
