6–Managing Ports
Viewing Port Information
59266-01 B 6-9
Table 6-7. Port Statistics Data Window Fields
Field Description
Start Time Beginning of the period over which the statistics apply:
Start time for the Absolute view is not applicable
Start time for the Rate view is the beginning of polling
interval
Start time for the Baseline view is the last time the
baseline was set
End Time Last time the statistics were updated on the display
Total Time Total time period from start time to end time
AL Init Number of times the port entered the initialization state
AL Init Error Number of times the port entered initialization and the ini-
tialization failed. Increments count when port has a sync
loss.
Bad Frames Number of frames that were truncated due to a loss of
sync or the frame did not end with an EOF
BB_CreditRecoveryFrame
Failure
Number of times more frames were lost during a credit
recovery period than the recovery process could resolve.
This generates a Link Reset to recover the credits.
BB_CreditRecoveryRRDY
Failure
Number of times more R_RDYs were lost during a credit
recovery period than the recovery process could resolve.
This generates a Link Reset to recover the credits.
Class 2 Frames In Number of class 2 frames received by this port
Class 2 Frames Out Number of class 2 frames transmitted by this port
Class 2 Words In Number of class 2 words received by this port
Class 2 Words Out Number of class 2 words transmitted by this port
Class 3 Frames In Number of class 3 frames received by this port
Class 3 Frames Out Number of class 3 frames transmitted by this port
Class 3 Toss Number of class 3 frames that were discarded by this
port. A frame may be discarded because a missing frame
or an E_D_TOV timeout is detected, a reject frame is
received, or a frame is received on an offline port.
Class 3 Words In Number of class 3 words received by this port
Class 3 Words Out Number of class 3 words transmitted by this port
