1–Using Enterprise Fabric Suite
Enterprise Fabric Suite User Interface
1-26 59266-01 B
Working with Ports
Ports are selectable and serve as access points for other displays and menus.
You select ports to display information about them on the data window or to
modify them. Context-sensitive popup menus appear when you right-click the
faceplate image or on a port icon. See “Managing Ports” on page 6-1 for detailed
port information.
Selected ports on the faceplate display are outlined in white. You can select ports
in the following ways:
To select a port, click the port.
To select all ports, right-click on the faceplate image, and click Select All
Ports on the shortcut menu.
To select a range of consecutive ports, click a port, press and hold SHIFT,
and then click the last port in the range. The Enterprise Fabric Suite
application selects both end ports and all ports in between the end ports.
To select several non-consecutive ports, press and hold CTRL while clicking
each port.
To deselect ports, press and hold CTRL while clicking each port.
To cancel a selection, press and hold CTRL, and click it again.
NOTE:
When using the SHIFT key to select a range of ports, the first port you click
in the range is the anchor selection. Subsequent ranges are based on this
anchor selection. For example, when you click port 4 and port 9 respectively,
port 4 becomes the anchor selection. The next range includes all ports
between port 4 and the next port you select.
