Qlogic 5800V Series User Manual

2–Managing Fabrics
Transparent Router
59266-01 B 2-17
5. In the Remote Fabric Zoning dialog box (Figure 2-6), if you made and saved
changes in the TR Mapping Manager dialog box, you can choose the type of
zoning commands to view in the Suggested Remote Fabric Zoning
Commands window of the Remote Fabric Zoning dialog box.
Choose one of the following options from Select Set of Zoning Commands to
View:
 The Comprehensive Zoning Commands for Initial TR Setup option to
show the list of zoning commands to set up all the IFZs.
 The Zoning Commands Only for Changes to TR Mappings option to
show the list of zoning commands only for changes you just made
during this session (after opening the TR Mapping Manager dialog
box).
6. Choose one of the following options from the Remote Switch Type
drop-down list to generate the corresponding zoning commands:
 Brocade—to connect remotely with Brocade switches
 Cisco—to connect remotely with Cisco switches
7. Enter the Configuration Name, which is used as the zone set name in the
commands. This must be the same zone set name as the zone set on the
remote fabric to which this zoning will be applied, or else the commands
generated can be saved and edited to change the zone set name as
needed. The default Configuration Name displayed is TRoutesCfg.
8. Select one of the following:
 Clear the New Configuration option if the remote fabric has an active
zone set. Executing the updated zoning commands on the remote
fabric automatically adds the changes to the already active zone set,
provided that the Configuration Name entered is the same as the
name of that active zone set.
NOTE:
The Remote Fabric Zoning dialog box displays the Select Set of Zoning
Commands to View option only if you made and saved changes in the TR
Mapping Manager dialog box. If you opened the Remote Fabric Zoning
dialog box after opening the File menu, and clicking Generate Remote
Zoning, the Select Set of Zoning Commands to View option is not
displayed, and the Suggested Remote Fabric Zoning Commands window
displays the list of zoning commands to set up all the IFZs.
