This procedure is used for a self-signed certificate or a certificate issued by a certificate authority.
1. Open a Web browser.
2. Enter "http://(the machine's IP address or host name)/" in the address bar.
When entering an IPv4 address, do not begin segments with zeros. For example: If the address is
"192.168.001.010", you must enter it as "192.168.1.10" to connect to the machine.
The top page of Web Image Monitor appears.
3. Click [Login].
The administrator can log on.
Enter the login user name and login password.
4. Click [Configuration], and then click [SSL/TLS] under "Security".
The "SSL/TLS" page appears.
5. Click [Active] for the protocol version used in "SSL/TLS".
6. Select the encryption communication mode for "Permit SSL/TLS Communication".
7. Click [OK].
The SSL setting is enabled.
8. Click [OK].
9. Click [Logout].
• If you set "Permit SSL/TLS Communication" to [Ciphertext Only], enter "http://(the machine's IP
address or host name)/" to access the machine.
User Settings for SSL (Secure Sockets Layer)
If you have installed a device certificate and enabled SSL (Secure Sockets Layer), you need to install the
certificate on the user's computer.
The administrator must explain the procedure for installing the certificate to users.
If a warning dialog box appears while accessing the machine using Web Image Monitor or IPP, start the
Certificate Import Wizard and install a certificate.
1. When the Security Alert dialog box appears, click [View Certificate].
The Certificate dialog box appears.
To be able to respond to inquiries from users about such problems as expiry of the certificate, check
the contents of the certificate.
2. Click [Install Certificate...] on the "General" tab.
Certificate Import Wizard starts.
8. Security Measures Provided by this Printer
342
