106 Rockwell Automation Publication 2198-UM005C-EN-P - February 2022
Chapter 6 Configure and Start up the Kinetix 5300 Drive System
Use the four-character display and menus t0 set the network settings. Refer to
Change the IP Settings on page 103 for instructions to update the following:
• IP address
•Subnet mask
• Gateway
Settings are stored in nonvolatile memory. IP addresses can also be changed
through the Module Configuration dialog box in RSLinx® software. Changes to
the IP address take effect after the power is cycled.
Studio 5000 Logix Designer For help using the Studio 5000 Logix Designer application as it applies to
configuring the ControlLogix® or CompactLogix™ controllers, refer to
Additional Resources
on page 10.
Version History
Each release of the Studio 5000 Logix Designer application makes it possible
for the configuration of additional Kinetix motors, actuators, or other drive
features not available in previous versions.
Table 61 - AOP Installation Requirement
IMPORTANT • Modified address octets must be within a valid range (0…255). The first
digit of every octet has a range of 0…2. Every other digit has a range of
0…9. When a digit is incremented over the upper boundary, the digit
resets to 0.
• If a modified network setting is invalid, NET ERR is displayed and you
must manually revert to the previous network settings.
• If a modified network setting is valid, ACCEPT is displayed. Press Select to
confirm the new setting.
• After you modify and confirm a network setting, press Back to apply the
settings.
IMPORTANT To configure additional drive features and/or motors with your
Kinetix 5300 servo drive, you must have drive firmware 13.001 or later.
Drive Catalog Number
Drive Firmware
Revision
Logix Designer Application
Version
Kinetix 5300 AOP Needed?
2198-Cxxxx-ERS 13.001 or later 33.00 or later No
