Siemens SIMOCODE pro System Manual

Motor control
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
4-9
4.1.4 Control station settings
Control stations Description
LC Activates the control station via an arbitrary signal
(arbitrary sockets ,
but usually device inputs).
The "OFF" plug is 0-active on the control station [LC].
ON<<
ON<
OFF
ON>
ON>>
PLC/PCS [DP] Activates the control station via an arbitrary signal
(arbitrary sockets ,
but usually control bits from PROFIBUS DP)
ON<<
ON<
OFF
ON>
ON>>
PC [DPV1] Activates the control stations via an arbitrary signal
(arbitrary sockets ,
but usually control bits from PROFIBUS DPV1)
ON<<
ON<
OFF
ON>
ON>>
Operator panel [OP] Activates the control stations via an arbitrary signal
(arbitrary sockets ,
but usually operator panel buttons)
<>/<<>>
ON<
OFF
ON>
ON>>
Mode selector For switching between the 4 operating modes Local 1,
Local 2, Local 3 and remote with arbitrary signals
(arbitrary sockets , e.g. device inputs, control bits
from PROFIBUS DP, etc.)
S1
S1
Table 4-3: Control station settings
