Siemens SIMOCODE pro System Manual

Logic modules
SIMOCODE pro
11-22 GWA 4NEB 631 6050-22 DS 03
11.10 Flickering
Description
You can use the "Flickering" logic modules to assign the "Flickering" function
to the operator panel LEDs (for example).
If an input signal is pending, the "Flickering" function block issues an output
signal with a frequency of 4 Hz.
The function block consists of:
• One plug
• One logic component
• One socket.
Overall, three logic modules, "Flickering 1" through to "Flickering 3" are available
for BU1 and BU2.
Schematic
The following schematic shows the "Flickering" logic modules:
Fig. 11-17: "Flickering" logic modules
Settings
Flickering 1 to 3 - Description
Input Activation by any signal
(any sockets ,
e. g. status information etc.)
Table 11-11: Flickering settings
Flickering 1
Input
Output
Flickering 2
Input
Output
Flickering 3
Input
Output
