Short instructions for configuring a reversing starter
SIMOCODE pro
2-6 GWA 4NEB 631 6050-22 DS 03
2.3 Parameterization
The basics of parameterization
After the external wiring has been carried out (contactor coils connected,
current measuring module integrated in the main circuit), SIMOCODE pro is
then parameterized.
For this you need to know the following points:
Point Description
1 Function blocks are stored internally in the SIMOCODE pro system, e.g. for
control stations, control functions and motor protection.
2 Function blocks have names.
3 Function blocks may have set values, e.g. the type of control function and the
set current for overload protection.
4 Function blocks are equipped with plugs and sockets. These are clearly
designated.
5 To achieve the desired functionality, proceed as follows:
• Connect the function blocks by connecting specific plugs to specific
sockets (i.e "plug the plugs into the sockets")
• If required, set values in the function blocks, e.g. the set current, type of
control function.
6 The inputs of the function blocks in the basic unit are designated as plugs
and labeled accordingly:
7 The outputs of the function blocks in the basic unit are designated as sockets
and labeled accordingly:
8 The plugs and sockets of the device inputs and outputs are not connected as
factory defaults. If you press a button now, the contactors will not be
activated.
Table 2-2: Schematic of the various SIMOCODE pro function blocks
